1μg (R: reducing condition, N: non-reducing condition).
Product Details
Product Details
Product Specification
Species | Human |
Synonyms | CLEC13D; CLEC13Dmacrophage mannose receptor 1; C-type lectin domain family 13 member D; mannose receptor, C type 1; MMRCD206 antigen; MRC1 |
Accession | P22897-1 |
Amino Acid Sequence | Leu19-Ala1389 with His Tag & Avi Tag at C-Terminus |
Expression System | HEK293 |
Molecular Weight | 140-170kDa (Reducing) |
Purity | > 95 % as determined by SDS-PAGE & > 90 % as determined by SEC-HPLC |
Endotoxin | <1EU/μg |
Conjugation | Biotin |
Tag | Avi Tag, His Tag |
Physical Appearance | Lyophilized Powder |
Storage Buffer | PBS, PH7.4, 5% trehalose |
Reconstitution | Reconstitute at 0.1-1 mg/ml according to the size in ultrapure water after rapid centrifugation. |
Stability & Storage | · 12 months from date of receipt, lyophilized powder stored at -20 to -80℃. |
Background
The MMR (macrophage mannose receptor), also known as MR, CD206, Mrc1, or CLEC13D, is a 175‑190 kDa endocytic receptor. It's expressed on M2 macrophages, tumor-associated macrophages (TAMs), and certain dendritic cells and endothelial cells. The human CD206 precursor (1456 aa) includes a signal sequence, an extracellular domain (ECD) with a cysteine-rich domain, a fibronectin type II repeat, eight C-type lectin domains (CTLDs), and N-glycosylation sites, followed by a transmembrane segment and a short cytoplasmic domain. The ECD can be shed by metalloproteinases. Human CD206 ECD shares high sequence identity with CD206 from other species.
The cysteine-rich domain binds pituitary hormones like LH and TSH, chondroitin sulfates, and sulfated N‑acetylgalactosamines. The FNII domain binds collagens without Ca2+, while CTLDs recognize branched sugars on pathogens in a Ca2+-dependent manner. CD206 internalizes ligands in clathrin-coated vesicles, sorts them to phagosomes or early endosomes, and recycles to the cell surface. It helps clear glycoproteins linked to allergy and inflammation, such as lysosomal hydrolases and myeloperoxidases. CD206 is involved in T cell polarization and cytokine production, facilitates peptide presentation on MHC II and cross-presentation on MHC I, which is crucial for tumor immunogenicity. This function may be blocked by tumor mucins engaging CD206 on TAMs.
SDS-PAGE
SEC-HPLC
Biotinylated CD206/MMR His&Avi Tag Protein, Human is greater than 90% as determined by SEC-HPLC.
ELISA
Immobilized Mannan from Saccharomyces cerevisiae at 20.0μg/mL (100μL/well) can bind Biotinylated CD206/MMR His&Avi Tag Protein, Human (Cat. No. UA011209) with EC50 of 1.608-1.872ug/mL.
