IHC shows positive staining in paraffin-embedded human tonsil. Anti- PD-L2 antibody was used at 1/100 dilution, followed by a HRP Polymer for Mouse & Rabbit IgG (ready to use). Counterstained with hematoxylin. Heat mediated antigen retrieval with Tris/EDTA buffer pH9.0 was performed before commencing with IHC staining protocol.
Product Details
Product Details
Product Specification
Host | Rabbit |
Antigen | PD-L2 |
Synonyms | Programmed cell death 1 ligand 2, PD-1 ligand 2, PDCD1 ligand 2, Programmed death ligand 2, Butyrophilin B7-DC (B7-DC), CD273, PDCD1LG2, B7DC, PDCD1L2, PDL2 |
Immunogen | Recombinant Protein |
Location | Secreted, Cell membrane |
Accession | Q9BQ51 |
Clone Number | S-1041-21 |
Antibody Type | Recombinant mAb |
Isotype | IgG |
Application | IHC-P |
Reactivity | Hu |
Purification | Protein A |
Concentration | 0.5 mg/ml |
Conjugation | Unconjugated |
Physical Appearance | Liquid |
Storage Buffer | PBS, 40% Glycerol, 0.05% BSA, 0.03% Proclin 300 |
Stability & Storage | 12 months from date of receipt / reconstitution, -20 °C as supplied |
Dilution
application | dilution | species |
IHC-P | 1:100 | null |
Background
PD-L2, also known as Programmed Death-Ligand 2 or B7-DC, is a protein encoded by the PDCD1LG2 gene, which is located on chromosome 9p24.2. PD-L2 is one of the two Programmed Death Ligands (PD-L) and a member of the CD28 family of immune receptors. In the human body, PD-L2 is widely expressed in various tissues, including the placenta, heart, pancreas, lungs, and liver, but its expression is relatively low in the spleen, lymph nodes, and thymus. PD-L2 plays multiple roles in the immune system. Firstly, it can bind to PD-1 and inhibit the immune activation of T cells through downstream signaling pathways such as tyrosine phosphatase-2 (SHP-2). Secondly, PD-L2 can also bind to repulsive guidance molecule b (RGMb), activating the bone morphogenetic protein receptor pathway and promoting the functional activation of T cells. This dual functionality makes PD-L2 an important player in immune regulation. Furthermore, PD-L2 plays a significant role in tumor immune evasion mechanisms. It can both activate and inhibit T cells and may contribute to the development of immune-related pneumonia. Some studies have suggested that the expression of PD-L2 is associated with poor prognosis in esophageal cancer, supporting its role as a prognostic biomarker.
Immunohistochemistry
IHC shows positive staining in paraffin-embedded human cervical squamous cell carcinoma. Anti- PD-L2 antibody was used at 1/100 dilution, followed by a HRP Polymer for Mouse & Rabbit IgG (ready to use). Counterstained with hematoxylin. Heat mediated antigen retrieval with Tris/EDTA buffer pH9.0 was performed before commencing with IHC staining protocol.
IHC shows positive staining in paraffin-embedded human thyroid cancer. Anti- PD-L2 antibody was used at 1/100 dilution, followed by a HRP Polymer for Mouse & Rabbit IgG (ready to use). Counterstained with hematoxylin. Heat mediated antigen retrieval with Tris/EDTA buffer pH9.0 was performed before commencing with IHC staining protocol.
